Açıklama : Product Type

High Precision Cleaver V7

Simple Optical Fiber Collector SC-V7-01

Fiber Holder FH-40-1

SOC Heater Cover HTS-SOC-03

AC Adaptor JS-1618

Cooling Tray CG-22

Electrodes E-50

Battery Pack LBT-3000

Power Cable ACC-25

USB Cable USB-5P

USB Cable USB-6P

Carrying Case ICC-50

Shoulder Strap ST-0

Splicing Technology Active Clad Alignment

Splicing Time 7sec (quick mode) / 9 sec (typical)

Heating Time 13 sec (45mm, slim 60mm), 15 sec (60mm)

Typical Loss 0.03dB(SM) / 0.01dB(MM) / 0.05dB(DS) / 0.05dB(NZDS) / 0.03dB(G.657)

Dimensions
Size (HWD) H: 124mm W: 144mm D: 131mm

Weight 1.56kg (including battery) / 1.31kg (without battery)
